| Acquisition Delay of Digital Camera | ||
|
Version française
|
The Acquisition Delay is the difference in time between the date of the end of exposure of an image and the date when this image is time-stamped by the video acquisition software.
Besançon Talk 2022
 |
Experimental setup
 |
The principle of the measurement method and calculation are described in the above document. In comparison with the device described in 2022, the LEDs have been replaced by three 1 mm diameter PMMA optical fibers. These fibers capture the light from a 1PPS LED available in a GPS module, TimeBox, Time Server, etc. ... The assembly opposite was produced using 3D printing. The corresponding .stl files are available here STL files |
Occult Tools
 |
The 'Acquisition Delay' module enables the calculation of one or three PPS signals for a given measurement chain.
Access to the Occult Tools page.
Last change 05/06/2024
Online 02/06/2022
